fitpeaks

Purpose

Peak fitting routine.

Synopsis

[peakdefo,fval,exitflag,out,fit,res] = fitpeaks(peakdef,y,ax,options)

Description

Based on the initial guess in input peakdef, FITPEAKS estimates the peak fit (also the Jacobian and Hessian), and makes a call to LMOPTIMIZEBND to find the best fit of the peaks to the data. (See LMOPTIMIZEBND for additional information.) Results are output to peakdefo.

Information about individual peaks is stored in standard peak structures (see PEAKSTRUCT). Information on multiple peaks is stored in a multi-record structure. Given a standard peak structure (peakdef) that contains an initial guess of peak locations and widths, FITPEAKS finds new parameters that best fits peaks to the rows of the  data matrix (y). Results are output to a standard peak structure (peakdefo).

Fields of (peakdef) required in the initial guess for each peak are (.fun), (.param), (.lb), (.penlb), (.ub), and (.penub).

INPUTS:

                peakdef   = multi-record standard peak structure with the following fields:

                     name:   'Peak', name indicating that this is a standard peak structure.

                         id:   ' ', double or character string peak identification.

                       fun:   [ {'Gaussian'} | 'Lorentzian' | 'PVoigt1' | 'PVoigt2' ], defines the peak function (see definitions in the Algorithm section).

                   param:   Parameter list for each peak function. The number of parameters depends on the peak function used:

                                 'Gaussian': [height, location, width],

                                 'Lorentzian': [height, location, width],

                                 'PVoigt1': [height, location, width, fraction Gaussian],

                                 'PVoigt2': [height, location, width, fraction Gaussian].

                         lb:   [ ], Lower bounds on the function parameters. This is a row vector with the same number of elements as peakdef.param.

                   penlb:   [ ], Penalty wt for lower bounds, >=0. This is a row vector with the same number of elements as peakdef.param. If set to 0 this constraint is not employed.

                         ub:   [ ], Upper bounds on the function parameters. This is a row vector with the same number of elements as peakdef.param.

                   penub:   [ ], Penalty wt for upper bounds, >=0. This is a row vector with the same number of elements as peakdef.param. If set to 0 this constraint is not employed.

                     area:   [ ], Estimated peak area.

                            y   = MxN measured responses with peaks to fit. Each row of (y) is fit to the peaks given in (peakdef).

OPTIONAL INPUTS:

                          ax   = 1xN x-axis to fit to {default ax=1:N}.

                options   = discussed below in the Options Section.

OUTPUTS:

              peakdefo   = The input peak structure (peakdef) with parameters changed to correspond to the best fit values.

                      fval   = Scalar value of the objective function evaluated at termination of FITPEAKS.

              exitflag   = Describes the exit condition (see LMOPTIMIZEBND).

                        out   = Structure array with information on the optimization/fitting (see LMOPTIMIZEBND).

                        fit   = Model fit of the peaks, i.e it is the best fit to (y).

                        res   = Residuals of fit of the peaks.

Algorithm

Peaks are fit to the functions defined below based on the definitions in the field (peakdef.fun). The functions can be evaluated using independent functions or a wrapper function PEAKFUNCTION. See PEAKFUNCTION for more help.

For peakdef.fun = 'Gaussian' the function is

where  is the  element of optional input (ax), and  corresponds to the peak parameters in the three-element vector (peakdef.param). Constraints that should be used are (bounds in peakdef) are  and .

For peakdef.fun = 'Lorentzian' the function is

                   .

Constraints that should be used are (bounds in peakdef) are  and .

For peakdef.fun = 'PVoigt1' the function is

where  corresponds to the peak parameters in the four-element vector (peakdef.param). Constraints that should be used are (bounds in peakdef) are  and , while . The Pseudo-Voigt peak shape is an estimate of the Gaussian and Lorentzian peak shapes convolved.

For peakdef.fun = 'PVoigt2' the function is

where  corresponds to the peak parameters in the four-element vector (peakdef.param). Constraints that should be used (bounds in peakdef) are  and , while . The Pseudo-Voigt peak shape is an estimate of the Gaussian and Lorentzian peak shapes convolved.

A comparison of the four peaks is given in the figure below, and was generated using the following code:

  ax     = 0:0.1:100;

  y      = zeros(4,length(ax));

  plot(ax,peakgaussian([2 51 8],ax),'-b', ...

       ax,peaklorentzian([2 51 8],ax),'--k', ...

       ax,peakpvoigt1([2 51 8 0.5],ax),':g', ...

       ax,peakpvoigt2([2 51 8 0.5],ax),'-.r')

  legend('Gaussian','Lorentzian','PVoigt1','PVoigt2')

Options

options = structure array with the following fields:

          name:  'options', name indicating that this is an options structure.

        display:   [ 'off' | {'on'} ] governs level of display to the command window.

           optimopts:   options structure from LMOPTIMIZEBND. This field is passed to LMOPTIMIZEBND and can be used to control the optimization / fitting.

Examples

%Make a single known peak

  ax            = 0:0.1:100;

  y             = peakgaussian([2 51 8],ax);

%Define first estimate and peak type

  peakdef       = peakstruct;

  peakdef.param = [0.1  43   5]; %coef, position, spread

  peakdef.lb    = [0     0  0.0001]; %lower bounds on param

  peakdef.penlb = [1e-6 1e-6 1e-6];

  peakdef.ub    = [10 99.9 40]; %upper bounds on params

  peakdef.penub = [1e-6 1e-6 1e-6];

%Estimate fit and plot

  yint   = peakfunction(peakdef,ax);

  [peakdef,fval,exitflag,out] = fitpeaks(peakdef,y,ax);

  yfit   = peakfunction(peakdef,ax); figure

  plot(ax,yint,'m',ax,y,'b',ax,yfit,'r--')

  legend('Initial','Actual','Fit')
